Product information:

Chipset: B75

CPU: G530/G540 and other series, equipped with CPU fan

Memory: Support DDR3L notebook memory; 4 G can meet the needs

2 USB2.0, 2 USB3.0

Support onboard VGA display

8 USB3.0 (8 are PCIEX1 signals) and 8 graphics card adapter boards are required

Support ATX power supply

Support SATA hard disk and MSATA hard disk (customers are recommended to use MSATA)

Support Linux and window 10 system

Motherboard size: 170*185mm, weight 0.565kg

Product features:

Specific chipset: The B75 chipset provides a stable infrastructure for the system.

CPU and heat dissipation: Supports G530/G540 series CPUs and is equipped with a CPU fan to ensure the heat dissipation effect when the CPU runs.

Memory support: SIt supports DDR3L notebook memory, and G memory can meet the needs, which reduces the cost to a certain extent.

Rich interfaces: It has 2 USB2.0 and 2 USB3.0 interfaces, which are convenient for connecting external devices.

Display support: It supports onboard VGA displays and can connect display devices without using independent graphics cards, which increases its flexibility of use.

Robust graphics card expansion: Eight USB 3.0 (PCIEX1 signals) can connect eight graphics card adapter boards to meet the needs of multiple graphics cards.

Power and storage support: It supports an ATX power supply to ensure a stable power supply. It also supports SATA and SATA hard drives. It is recommended that customers use mSATA hard drives to provide users with a variety of storage options.

System compatibility: Supports Linux and Windows 10 systems to meet the operating system requirements of different users.

Compact size and lightweight: The motherboard measures 170*185mm, takes up little space, and is easy to install in a small chassis. The TA single chip weighs 0.565 kg, which is relatively light and easy to carry and install.

Application areas:

Multi-graphics card computing environment: Suitable for scenarios that require parallel computing of multiple graphics cards, such as scientific computing, data analysis, artificial intelligence, etc. The expansion capacity of 8 graphics cards can provide powerful computing performance.

Digital currency mining: This motherboard’s multi-graphics card support is an important advantage for digital currency miners. Eight graphics cards can be connected for mining, which improves mining efficiency.

Small studios and personal users: For small video editing studios, 3D modelling studios or individual users, certain computing and graphics processing capabilities are required. This motherboard can meet their needs for multiple graphics cards, while being compact in size and suitable for small workspaces.

Server applications: In some small server applications, multiple graphics cards can provide additional graphics processing capabilities or be used for specific computing tasks. This motherboard’s stability and compatibility make it suitable for some specific server scenarios.

Education and training: It can be used in computer training laboratories or computer courses in schools to help students understand the construction and application of multi-graphics card systems and improve their practical ability.
